EN5311QI 5A Synchronous Buck Converter 4.5-36V Input 95% Efficiency QFN-20 -40°C to +125°C AEC-Q100

EN5311QI 5A Synchronous Buck Converter 4.5-36V Input 95% Efficiency QFN-20 -40°C to +125°C AEC-Q100

FEATURES
Revolutionary Integrated inductor

5mm x 4mm x1.1mm QFN package

Very small total solution foot print

APPLICATIONS
Area constrained applications

Noise Sensitive Applications such as A/V and RF

LDO replacement for improved thermals

Set top box/home gateway

Smart phones, PDAs
VolP and Video phones

Personal Media Player

DESCRIPTION
The Ultra-Low-Profile EN5311Ql is targeted toapplications where board area and profile are critical.EN5311Ql is a complete power conversion solutionrequiring only two low cost ceramic MLCC caps.Inductor,MOSFETS,PWM,and compensation areintegrated into a tiny 5mmx4mm x1.1mm QFNpackage. The EN5311Ql is engineered to simplifydesign and to minimize layout constraints. 4 MHzswitching frequencyand internal typelcompensation provides superior transient response.With a 1.1 mm profile, the EN5311Ql is ideal for spaceand height constrained applications.

A 3-pin VD output voltage selector provides sevenpre-programmed output voltages along with anoption for external resistor divider. Output voltagecan be programmed on-the-fly to provide fast,dynamic voltage scaling.
